Samsun MXS-2800 Professional Power Amplifier

Samsun MXS-2800 Professional Power Amplifier Overview:

he MXS2800 Professional Power Amplifier by Samson is for sound reinforcement. It can be used in various environments in audio applications such as, live sound, boardrooms, schools, DJ setups, and more. It features a Class D two channel amplifier, with 850 watts per side at 4 ohms, 3,400 watts bridged mono at 4 ohms. The amp is built with XLR and RCA inputs, Speakon outputs and has dented level controls for each channel. 10 dB peak level LED indicators provide optimal use when on dark stages.

In addition, the MXS 2800s two-position mode selector switch, allows for easy toggling between stereo and bridged mono modes. A built-in limiter provides peak power delivery while minimizing distortion. Designed to support efficient and safe performance, Samson's MXS professional power amplifier offer pro-level power solutions for live music venues, houses of worship and health clubs.

Features:

• Single rack space, lightweight Class D power amplifier

• 850 watts per side at 4 ohms, 3,400 watts bridged mono at 4 ohms

• 450 watts per side at 8 ohms, 1,700 watts bridged mono at 8 ohms

• Built-in limiter provides peak power delivery while minimizing distortion

• Extensive 4-point protection circuitry (Short Circuit, DC Output, Over Current, Thermal)

• Front panel LED indicators to monitor for Signal, 10 dB, Peak

• 2 position mode switch for stereo and bridged mono

Specifications:

• Inputs
  • 2x 3-pin XLRF

  • 2x RCA

• Outputs: 2x Speakon

• LED: Front Panel: Signal, 10 db, peak

• Switch Controls: 2-Position Mode: Stereo, bridged mono

• Protection Circuits: 4-Point Protection: Short circuit, DC output, over current, thermal

• Limiter: Provides peak power delivery while minimizing distortion

• Wattage
  • 850 W per side at 4 ohms

  • 3,400 W bridge mono at 4 ohms

• Power: 120 VAC

• Dimensions: 4.5 x 21 x 14.25" (11 x 53 x 36 cm)
