Ibanez TOD10 Tim Henson Signature 6 String Electric Guitar
Ibanez TOD10 Tim Henson Signature 6 String Electric Guitar Overview:
Oval C Roasted Maple neck
The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.
Ebony fretboard
Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.
American Basswood body
The American Basswood body delivers a natural and flat tone.
Fishman Fluence Tim Henson Signature Series pickups
Tim's signature Fishman Fluence pickups span the entire range of aggressive lead and rhythm tones to the cleanest of clean single coil combinations, even touching on sounds Tim was previously only able to produce with his acoustic guitars.
Neck Pickup Voice 1: Thick and smooth neck humbucker / Voice 2: Hyper-clean, nylon string surrogate/ Voice 3: Tim's fluid neck single coil
Bridge Pickup Voice 1: Based on Fishman's hot-rodded Classic voice, the quintessential lead tone of generation / Voice 2: Combination of Tim's favorite bridge humbuckers / Voice 3: Tim's ideal single coil combination tone when used in conjunction with neck coil
Gotoh T1502 tremolo
The T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.
Fishman Fluence Voicing switch on tone control (push/pull) for Tim Henson Signature Series pickups
The Voicing switch allows the pickups to switch between three musically complementary voices.
Specifications:
- neck type AZ Oval C Roasted Maple neck
- top/back/body American Basswood body
- fretboard Ebony fretboardTree of Death inlay
- fret Jumbo Stainless Steel frets
- number of frets 24
- bridge Gotoh T1502 tremolo bridge
- string space 10.5mm
- neck pickup Fishman Fluence Tim Henson Signature Series (H) neck pickupActive/Alnico
- bridge pickup Fishman Fluenceā¢ Tim Henson Signature Series (H) bridge pickupActive/Alnico
- factory tuning 1E,2B,3G,4D,5A,6E
- strings D'Addario EXL110
- string gauge .010/.013/.017/.026/.036/.046
- nut Graph Tech
- hardware color Chrome
NECK DIMENSIONS
- Scale : 648mm/25.5"
- a : Width 42mm at NUT
- b : Width 57mm at 24F
- c : Thickness 20.5mm at 1F
- d : Thickness 22.5mm at 12F
- Radius : 305mmR
